Garmin GT56UHD-THP
Original price was: R36, 299,00.R31, 620,00Current price is: R31, 620,00.
You’re now subscribed to price tracking for this product. We’ll notify you if the price drops.
Description
LESS TIME FINDING. MORE TIME FISHING.
This all-in-one transducer offers ultimate versatility, featuring Ultra High-Definition ClearVü and SideVü scanning sonars, high wide CHIRP traditional sonar and more, so you can spend more time catching fish.
 |
 |
 |
 |
 |
| See everything below and around your boat with Ultra High-Definition scanning sonar. | High wide CHIRP traditional sonar delivers target separation like no other. | Multiple sonar frequencies have you covered — no matter what depth you’re fishing. | See targets and structure in bright, vivid colour. | Mount this transducer your way — transom, trolling motor or thru-hull. |
ULTRA HIGH-DEFINITION CLEARVÜ SCANNING SONARGet brilliant image clarity of structure and fish below your boat at greater depths than other high-frequency scanning sonars. It puts more power on targets via a downward-facing element. |
ULTRA HIGH-DEFINITION SIDEVÜ SCANNING SONARSee everything the first time with stunningly clear images of structure and fish off to the sides of your boat. SideVü sonar now has 20% greater range at 1,000 kHz, so you can see even farther than before. |
HIGH WIDE CHIRP TRADITIONAL SONARExperience remarkably clear target separation and definition up to 244 m (800 feet) below your boat. |
MULTIPLE SCANNING SONAR FREQUENCIESUse the perfect frequency for the waters you’re fishing. This transducer delivers 455 kHz, 800 kHz and 1,000 kHz for top performances at all depths. |
VIVID COLOUR PALETTESHigh-contrast vivid scanning sonar colour palettes make it easier than ever to distinguish targets and structure. |
MOUNTING OPTIONSEveryone’s setup is different. That’s why we’ve included transom, trolling motor and thru-hull mounting hardware. |
Specifications
General |
|
| Transducer frequency | Traditional High wide CHIRP (150-240 kHz); ClearVü/SideVü 455 kHz (425-485 kHz), 800 kHz (790-850 kHz), 1000 kHz (940-1100) |
| Transducer power | Traditional 350 W; ClearVü/SideVü 500 W |
| Transducer beamwidth | Traditional CHIRP: 24-16; ClearVü 0.52 x 52 @ 1000 kHz, 0.64 x 35 @ 800 kHz, 1.1 x 52 @ 455 kHz; SideVü 0.52 x 52 @ 1000 kHz, 0.64 x 35 @ 800 kHz, 1.1 x 52 @ 455 kHz |
| Transducer maximum depth | Traditional: 244 m freshwater; ClearVü: 122 m; SideVü: 152 m |
| Transducer cable length | 7.62 m |
| Transducer depth/speed/temperature | Depth and temperature |
| Transducer number of pins | 12 |
| Transducer supported deadrise/transom angles | 0°-70° degree transom |
In the box
- Depending on the version selected:
GT56UHD-TM
- GT56UHD-TM transducer
- Transom mount
- Mounting hardware
- Ferrite beads
- Documentation
GT56UHD-TH
- GT56UHD-TH transducer
- Stainless steel stem
- Fairing block
- Isolation plate and bushings
- Extension cable
- Mounting hardware
- Documentation
GT56UHD-THP
- 2 GT56UHD-TH transducers
- Stainless steel stems
- Fairing blocks
- Isolation plate and bushings
- Y-cable
- Mounting hardware
- Documentation
